MIFARE® Data Sector Reader/Writer, giao tiếp USB

Thương hiệu : AceProx, CHLB Đức

Multi Sector MIFARE® Reader/Writer: Đầu đọc ghi thẻ Mifare trên nhiều sector (Multi Sector MIFARE® Reader/Writer) được thiết kế để làm việc với thẻ MIFARE® Classic 1K/4K, MIFARE Plus® X/MIFARE Plus® S (in security level 1) và MIFARE Ultralight®. Kết nối máy tính qua USB (Virtual serial port via USB)

Công nghệ cao

Công nghệ tiên tiến làm nên sản phẩm chất lượng cao

Bảo hành

Bảo hành nghiêm túc theo tiêu chuẩn của nhà sản xuất

Hỗ trợ kỹ thuật

Hỗ trợ kỹ thuật trong suốt vòng đời sản phẩm

Uy tín thương hiệu

15 năm kinh nghiệm với hơn 3000 khách hàng đã tin tưởng sử dụng

MIFARE® Data Sector Reader/Writer, giao tiếp USB

Đầu đọc ghi thẻ Mifare trên nhiều sector (Multi Sector MIFARE® Reader/Writer) được thiết kế để làm việc với thẻ MIFARE® Classic 1K/4K, MIFARE Plus® X/MIFARE Plus® S (in security level 1) và MIFARE Ultralight®. Kết nối máy tính qua USB (Virtual serial port via USB)

The 727-52 multi sector 13.56MHz contactless MIFARE® Reader/Writer operates with MIFARE® Classic 1K/4K, MIFARE Plus® X/MIFARE Plus® S (in security level 1) or MIFARE Ultralight® cards.The Reader uses a PHILIPS MIFARE® Reader IC and complies to ISO 14443A. A USB interface is used to communicate between the unit and a PC.When plugged into the PC the device enumerates as a virtual serial port. The Reader has three independent LED´s and a beeper which are controlled via commands.

The multi sector MIFARE® Reader/Writer can read and write to any sector and block on the card and is MAD (Mifare Application Directory) compliant. All the encryption needed to provide a secure and reliable transaction is handled automatically with a few simple commands.

MIFARE® Data Sector Reader/Writer, giao tiếp USB

Attributes

  • Supports MIFARE® VALUE function
  • Reads MIFARE® Cards Unique ID Number (UID)
  • Supports MAD1 and MAD2
  • Reads and writes MIFARE® Classic, MIFARE Ultralight® , MIFARE Plus® , NTAG2XX
  • Read and write to any sector and block on the card
  • Reader can store 32 keys for use as A or B keys and 16 128 bit AES keys for MIFARE Plus®
  • Supports optional 128 bit AES authentication of MIFARE Plus® cards to prevent card copying and tampering

Application ranges

  • Integration into existing MIFARE® based applications
  • Security Systems, i.e. access control with biometric data on the card
  • Leisure Parks
  • City or Island Cards
Buzzer Yes
Buzzer kontrolle Cable
Dimensions (LxBxH) mm 118 x 54 x 21
Frequency 13,56MHz
Interface Connected via USB
LED 3
LED Control Cable
Operating Temperature Range 0°C to +50°C
Operating Voltage Powered by USB 5V DC, 100mA
Reading Distance 20 to 50mm depending on transponder
RFID Transponders Supported Compatible with MIFARE® Classic 1K / 4K, MIFARE Plus® X/S SL1 and MIFARE Ultralight®,
NTAG 2XX
Type of Transponder Passive Transponder
Weight (in g) 185
  • Hãng sản xuất: AceProx (Đức)
  • Mã hiệu sản phẩm: 727-52 Multi Sector MIFARE® Reader/Writer

Tải Datasheet tại đây
